Acer One 522 - LCD Panel Installation

3-44 Machine Maintenance Procedures
LCD Panel Installation 0
1. Install and connect LVDS cable (G) to panel connector (H). (Figure 3-45).
2. Secure transparent adhesive protector (J) to LVDS cable (G) and panel.
3. Install and secure CCD module cable (F) to panel.
4. Install LCD panel to LCD module cover. (Figure 3-43)
5. Secure adhesive foil tabs (E) securing LVDS cable to module cover.
6. Install and secure four (4) screws (C) to module cover.
7. Install CCD module.
ID Size Quantity Image
CM2x3 4
