3-8 Machine Maintenance Procedures
Battery Pack Removal 0
1. Place computer on flat surface, battery side up. (Figure 3-3)
2. Push battery lock/unlock latch (A) to unlock position.
3. Push and hold battery release latch (B) to release position.
4. Pull battery pack (C) from lower cover
Figure 3-3. Lower Cover Overview with Battery
Follow local regulations for battery (C, Figure 3-3) disposal.
Battery Pack Installation 0
1. Hold latch (B) in release position and install battery (C). (Figure 3-3)
2. Lock battery lock/unlock latch (A).
