2-16 System Utilities
DOS Flash Utility 0
Perform the following to use the DOS Flash Utility:
1. Press F2 during boot to enter Setup Menu.
2. Select Boot Menu to modify boot priority order.
3. Move USB HDD to position 1 (Figure 2-14). (Refer to Boot menu)
Figure 2-14. Changing BIOS Boot Priority Order
4. Copy BIOS.BAT to USB HDD.
5. Insert USB HDD and reboot computer.
6. Execute BIOS.BAT to update BIOS (Figure 2-15). BIOS flash process begins as shown in
Figure 2-16.
Figure 2-15. Executing BIOS.BAT
Boot priority order:
1. IDE0: ST960821A
2. IDE 1: MATSHITADVD
3. USB FDD:
Item Specific Help
Use <> or <> to select
a device, then press <F5>
to move it down the list, or
<F6> to move it up the list.
Press <Esc> to escape
the menu.
3.5
4. Network Boot: Realtek Boot Agent
5. USB HDD: xxxx USB
6. USB CDROM:
To Next Page
