Acer One 522 - Lower Cover Door Removal

3-12 Machine Maintenance Procedures
Lower Cover Door Removal 0
Prerequisite:
Battery Pack Removal
1. Remove four (4) screws (A) lower cover. (Figure 3-7)
Figure 3-7. Upper Cover without Keyboard
2. Use a tool to push through opening (B) to separate door from lower cover.
3. Remove door from lower cover.
A
A
A
A
B
