5-4 Jumper and Connector Locations
Figure 5-2. Mainboard Bottom
Table 5-2. Mainboard Bottom
Item Description Item Description
JMINI1 3G Connector JMINI2 WLAN Connector
JMINI2
WLAN Conn
JMINI1
3G Conn
