4
tenement house where one uniphone is used by several apartments on the same
floor.
Door entry units feature one built-in input activated by short circuit to ground. It is
used to connect an external “doorbell" button, such as INS-OB. The default
operating mode is direct opening of the door (E-lock activation) - for instance
when leaving the staircase. It is also possible to set door opening delay or switch
to direct call mode. The door opening delay is programmable in installer's menu
and the mode settings can be changed using a computer software.
The units also feature a second built-in relay output (only Master panels), which
can be used to control additional devices such as another gate, lighting, etc.
These additional devices can be controlled both from the uniphone (F2 button)
as well as by using individual resident codes or proximity cards/key fobs. Slave
panels require an optional CDN-I/O input/output module with 2 NO/NC relay
outputs and two inputs activated by short circuit to ground. The CDN-I/O module
may also be used in Master panels and can support a number of applications,
described in the computer program or on the website.
The unit features an output for connection of a standard or reversible E-lock.
Use CDN-PK relay module to connect another device in place of the E-lock.
It is also possible to use one door entry unit to control two pairs of doors - to open
the right apartment door (CDN-I/O module required). Apartments can be freely
assigned for opening specific door.
Use the optional CDN-USB cable and the computer software that can be
downloaded free of charge from www.support.aco.com.pl to program settings,
create backups and transfer settings to other units. Use the "x700" software to
manage unit’s settings and the "ACC_v70" software (version v7.0 or later) to
manage proximity cards or key fobs
The 700 series door entry units are also highly resistant to theft and tampering.
Even stolen unit is useless without the installer password.
II. TECHNICAL PARAMETERS
Number of subscribers (individual addresses): up to 255 programmable,
possible expansion to 1020 (INSPIRO+ only) with 4-zone module (SW4S-
DIN).
Six characters, large and heated LCD display (improved readability at low
temperatures),
Audio system power supply: (12V ± 0.5V) AC or 15V DC,
Video system power supply (including Audio):
15V DC,
Minimum power consumption in standby mode ~0.6W,
Current consumption of door entry units (without E-lock and additional
modules):
- CDNP7ACC: 290mA
