14
Available receivers:
1. Passive audio receivers, connected using a 2-core cable (INS-UP, INS-
UP720B, INS-UP720M). For these receivers, all terminals of receivers and units:
"LINE +" and "LINE -" are connected in parallel. These receivers can by supplied
by an AC, 11.5VAC (12VAC) / 1.2A transformer. Alternatively, by a DC power
supply: 15VDC / min. 1.5A.
2. Active audio receivers that require additional power supply (INS-UP720MR,
UP800). These receivers also require at least a 4-core cable or UTP for
connection. For these receivers, all terminals of receivers and units: "LINE +" and
"LINE -" are connected in parallel; power supply must be provided to receivers.
These receivers require a DC power supply: 15VDC / min. 2,8A. Small
installations will run on one power supply, supporting the unit and appropriate
number of receivers. Refer to relevant receiver manuals for more information.
When using UTP, receivers can be connected via CDNARu-DIN Audio Splitter.
3. Video inside units for video door entry systems. These receivers require UTP,
min. cat 5e, for connection. They also require a 15VDC / min. 2.8A power supply.
Small installations will run on one power supply, supporting the unit and
appropriate number of receivers. Refer to relevant receiver manuals for more
information.
CDNVRa or CDNVRau-DIN video splitter (or similar) must be used to connect
receivers.
2. Installation:
Install the receivers according to installation instructions. When connecting the
device make sure that the physical address is correctly set by jumpers or
switches (default physical address of the uniphone corresponds to the number
selected using the keypad).
In case of passive receivers, it is very important to avoid having receivers with
the same addresses in the system (in the same zones), each receiver in the
system must have its individual physical address set.
The above condition can be ignored in case active receivers that are designed to
work with the same physical address. In this case, the system (the same zone)
may feature several receivers with the same address.
For audio receivers, it is necessary to make sure that connection (polarity) to the
"LINE" terminals of the unit is correct. Before connecting video display units make
sure that all RJ connectors are properly clamped (in T568B standard), that no
short circuits on wires are present and that wires conduct properly. If even one
RJ connector is badly clamped or in case of a short circuit between wires, the
video inside unit, splitters, the combiner or the unit may be damaged.
VI. INSTALLATION
Visit www.aco.com.pl for information on installation, including exact dimensions
of the units, and refer to data sheets of individual products. Refer to the website
also for a long list of mounting components (which is expanding by the day).
Install the unit on building wall (vestibule, sheltered wall, east wall, etc.) so that
to minimise the effect of adverse weather conditions. The recommended height
To Next Page
