ACO CDNP7ACC - CDN-I;O Module: Inputs and Outputs

13
CDNVS combiner mode must be used for Master panels and CDNVSp - for Slave
panels.
Combiner modules are connected only to the "EXTMOD2" port (top port).
7. CDN-I/O module (additional 2 inputs and 2 outputs)
The module features two programmable ports: P1 and P2. Each of these ports
has an INPUT and a relay OUTPUT.
Inputs can be used for calling or opening and outputs can be used as control of
opening an additional entrance gate, switching on the staircase lighting, etc.
Module parameters can be configured in the unit using the intercome software
(x700) in section "CDN I/O".
General description of module functions:
The inputs of both ports can be used independently:
- to call opening
- to call apartments
- to enable OUTPUT
The outputs of both ports can be used independently:
- to activate output for pre-set time after setting the input of the same port
- to activate output for pre-set time before each opening call
(this function can be disabled for selected apartment, for instance to control two
pairs of doors using one unit)
- to activate output for pre-set time after pressing the second F2 button in the
receiver during connection, or to call opening with an additional code or proximity
card/key fob (this function can be disabled for selected apartment)
- to activate output for pre-set time after pressing any button on unit’s keypad or
additional modules
- to activate output for pre-set time without conversation (upon picking up the
handset and pressing the open button on passive receivers three times or only
upon pressing once the open button on active receivers)
The following function is available without physically connected module
- calling the opening without conversation (upon picking up the handset and
pressing the open button on passive receivers three times or only upon pressing
once the open button on active receivers)
Refer to x700 program for detailed description of functions and some examples
of module applications (click “ ” in outside unit parameters, section CDN I/O).
V. RECEIVERS - INFORMATION AND ASSEMBLY
1. Information:
Door entry units work with receivers with digital address decoding:
- INS-UP, INS-UP720, UP800 series audio receivers
- INS-MP (2.5-inch, 3.5-inch and 4-inch), INS-MP7 (7-inch) and MP800/UP800V
(2.5-inch, 3.5-inch) series monitors.
