Power supply voltage of window backlight: 12VAC or 15VDC. Terminals of the
module are connected to 12VAC power supply terminals of the panel with a two-
wire cable - parallel to power supply wires or (in Video systems) to 15VDC, or to
terminals of the panel: +DC (+ ELOCK) and GND (- LINE).
Modules 6N and 17N for CDNP7 are also available with the ACC reader of
proximity cards and key fobs hidden under the window. Modules can be
connected to any EXTMOD port in the unit and adding cards/key fobs is possible
directly from the numeric keypad of the unit, in the installer's menu P12: "M-ACC."
Full programming of the module (adding, deleting, moving and archiving
cards/key fobs) is possible only vi a PC, using the optional CDN-USB cable and
software, version v3.0: "ACC_v35."
Note! In this case, the reader works only in zone 1 and supports 6 cards or key
fobs for each apartment and 6 administrator’s cards or key fobs: 1530 in total.
Refer to the “Extended user instruction for the CDNP5, CDNP6 (CDNP6ACC)
digital door entry system” for detailed description of this operation of the reader.
5. xNP series modules, like 2NP, 6NP and 10NP, are backlit windows of different
sizes with call buttons (x marks the number of buttons). Buttons can be
programmed for calling any apartment in zone 1, while windows can be used for
entering, next to the button, names, company names or other information about
the address, calling, etc.
The following modules are available for the CDNP7 series:
- 2NP - 2 call buttons as well as 52 mm wide and 46 mm high window
- 2NP - 6 call buttons as well as 52 mm wide and 102 mm high window
- 10NP - 10 call buttons as well as 52 mm wide and 160 mm high window
Refer to www.aco.com.pl for push-button versions available for the INSPIRO+
series.
Module can be connected to any EXTMOD port in the unit and programmed
directly from the numeric keypad of the unit, in the installer's menu P13: "M-xNP"
or using the optional CDN-USB cable and computer software: "FAM_P" (version
v15 or later). The programs are available for free download at
www.support.aco.com.pl
6. Camera module for video door entry systems
CDNVK camera module is available for CDNP7 series units; some INSPIRO+
are offered with built-in camera module.
For both unit models it is the same high-resolution colour camera (min. 600 lines)
with a 2.8 mm wide-angle lens. It features IR LED (infrared) backlight that
automatically switches on after dusk and ensure image visibility in the dark
(monochrome).
The video output of the camera is a PAL (symmetrical) signal, so it requires a
combiner, which can be connected the camera module. Typically, the combiner
is installed directly in the door entry unit and provides power supply to the camera
module as well as converts the PAL signal into a differential signal transmitted in
ACO video door entry system bus, based on UTP (min. cat 5e). This type of bus
is used for all video inside units.
