5
- INSPIRO+ 1: 250mA
Current consumption of additional modules:
- electronic resident list module (230E module): 90mA
- RFID proximity card and key fob reader module: 40mA
- camera module: 150mA
- illuminated description window modules: 5mA
Permitted load of E-lock output: 1A (0.5A for reversible)
Permissible load - second output (relay): 2A, 30VDC;
Maximum line length: Audio 300m*, Video: 70m to last power supply - max
300m* using additional power supplies,
(*length for cable cross sections 0.5mm - refer to page 13 for more
information)
CDNP7 housing: powder coated aluminium alloy casting with 3mm
hexagon screws.
Frames for flush-mounting of CDNP7:
- CDN-R2-S small frame: dimension 229x111, mounting dimension:
210x92x33.5 (including 1.5mm flange); suitable only for CDNP7 or other
module of the same height (such as CDN-10N);
- CDN-R2-M medium frame: dimension 290.5x111, installation dimension:
271.5x92x33.5 (including 1.5mm flange); suitable for CDNP7 and small
modules (such as CDN-5N)
- CDN-R2-L large frame: dimension 352.5x111, mounting dimension:
333.5x92x33.5 (including 1.5mm flange); suitable for CDNP7 and medium
modules (such as CDN-6N)
- any number of frames of the same size can be combined horizontally or
vertically using mounting components
INSPIRO+ housing: stainless steel mounted using 4mm Allen screws for
3mm Allen key,
- Panel dimensions: width 111mm, other dimensions depend on panel version -
refer to product data sheets (catalogues) of individual panels for detailed
information or visit www.aco.com.pl
- Refer to product data sheets (catalogues) of individual products for detailed
information or visit www.aco.com.pl for dimensions required for installation of
relevant panels:
III. OPERATION
In standby (factory settings) the display shows "aco". Using a PC, this can be
changed to any other 6-character inscription or to 6 different screens (6
characters each), displayed in cycles with any interval in the range of 1 second
to 16 seconds. The displayed text can also be set as a scrolling message with
pre-set scrolling rate, by typing "_" after the last character.
To call an apartment, its number must be selected using the keypad (the number
will appear on the display). Within 3 seconds the receiver in the apartment will
start ringing. The pre-set number range is 1 to 255, which corresponds to the
physical addresses in the receivers. Using the computer program (“List of call
numbers") it is possible to set any call number in the range 0 to 999999 (with "0"
