Control of the built-in second relay OUTPUT:
The OUTPUT exit (Master panels only) can be activated upon pressing the F2
button in the receiver or entering the user code - in which case the "key" button
must be pressed twice before entering the code, which is the same as the basic
access code. Typically, exit is possible only during the connection (conversation).
Exit can also be activated without having to connect with the apartment - refer to
the I/O module settings in the computer program for details.
In this case, on classic uniphones the handset must be picked up and the open
button pressed three times, on active receivers (INS-UP720MR, UP800/MP800,
INS-MPx) the open button must be pressed once.
The response time and functions of the OUTPUT exit can be changed via the
computer program (similar as for port 2 of the CDN-I/O module). The default
response time is 1s. Slave panels must feature an optional CDN-I/O module.
At exit the display shows “Exit-2"
Exit control for individual premises can be disabled.
In units with the ACC proximity reader, the second output can also be activated
without pressing the "key" button and the proximity card or proximity key fob
(resident’s or administrator/installer’s).
The unit detects a short-circuit of uniphone lines - displaying the "LineEr”
message. During this time, E-lock can be activated by pressing any button and
building can be exited. When the correct state of the line is detected (when short
circuit ceases), it is automatically restored to normal operation.
Refer to the "Solving common problems" section at the end of this manual for
more information and description of common problems.
IV. DESCRIPTION OF ADDITIONAL AND SPECIAL MODULES
The 700 series door entry units support a great number of additional and special
modules. For CDNP7 series additional modules can be added independently
(can be purchased as separate modules), while the INSPIRO+ series is available
in specific versions with modules already installed. Refer to www.aco.com.pl for
full list of additional modules and versions of INSPIRO+. All transparent parts are
made of scratch-resistant polycarbonate.
PLEASE NOTE! Modules may only be connected with the power supply switched
off.
The following module types are available:
1. 230E module (v7.0 version) - electronic directory of names with information
displayed on a two-line LCD display. Names are arranged alphabetically and can
be viewed using the two arrow keys. Pressing the call button activates calling the
name or being displayed. The module supports as many 1020 items of 30
characters each (16 characters in the top line and 14 in the bottom line). It only
displays apartments with assigned tags (such as names). The display time is
limited to some 10s. After 10 seconds the display switched to Intro, where any
text can be typed in two lines of 16 characters each, for instance building address,
name, servicing company telephone number, etc. Up to 4 different Intro’s can be
