6146/6156 DC Voltage/Current Generators Operation Manual
4.2.3 Operations in Memory Recall Mode
4-6
4.2.3 Operations in Memory Recall Mode
The memory recall mode scans the source values stored in the memory from the first number to the last
number.
The following figure shows operations in the memory recall mode.
Table 4-4 Operations in Memory Recall Mode (1 of 3)
Operational
condition
Scan Mode Description Operation Remarks
Operate ON Repeat
Scans the
data
repeatedly at
intervals
specified by
the step time.
Tp:
Step time
Td:
READY output
delay time
Tcn:
Operate pro-
cessing time
Trc:
Range change
processing time
Single
Scans the
data at
intervals
specified by
the step time.
Hold
Scans the
data one by
one by
trigger input.
TRIGGER IN
SYNC OUT
READY OUT
Start trigger Hold trigger Hold release trigger
Output
Operate
Standby
Stored value
of the first
number
Stored
value of the
first number
TRIGGER IN
SYNC OUT
READY OUT
Start trigger
Hold trigger
Hold release trigger
Output
Operate
Standby
Stored value of the last
number
Stored value of the
first number
Stored value
of the first
number
TRIGGER IN
SYNC OUT
READY OUT
Step trigger
Output
Operate
Standby
Stored value of the last number
Stored value
of the first
number
Stored value
of the first
number
