6146/6156 DC Voltage/Current Generators Operation Manual
4.2.9 External Control Signals
4-21
4.2.9 External Control Signals
These signals are I/O signals for synchronizing multiple units, scanner or DMM control, interlock and
other external controls.
The following table shows the signal names, levels and functions.
Table 4-8 External Control Signal Functions
Signal
Input/
Output
Level Impedance Function
TRIGGER IN Input TTL negative
pulse
(2 μs or more)
Approx. 10 kΩ Start/step up in the sweep source mode or
memory recall mode
Stops continuous operation.
SYNC OUT
*1 *3
Output TTL negative
pulse
(Approx. 10
ms)
Approx. 100 Ω
open drain
(Pulled up to +5 V
by 4.7 kΩ)
Step up signal in the memory recall mode
or in the sweep source mode.
Step up signal for the continuous function
in the DC source mode.
READY OUT
*1 *4
Output TTL negative
pulse
(Approx. 10
ms)
Approx. 100 Ω
open drain
(Pulled up to +5 V
by 4.7 kΩ)
Outputs a pulse 10 ms or 50 ms after
changing the setting value.
STANDBY IN
*2
Input TTL negative
level
Approx. 10 kΩ Sets Standby when the signal level
changes from LO to HI.
OPERATE
STANDBY IN
*2
Input TTL negative
level
Approx. 10 kΩ Sets Standby when the signal level
changes from LO to HI.
Sets Operate when the signal level
changes from HI to LO.
INTERLOCK
*2
Input TTL negative
level
Approx. 10 kΩ Sets Standby when the signal level
changes from LO to HI.
When the signal is "HI" or Open, Operate
cannot be turned ON.
OPERATE OUT
*2
Output TTL negative
level
Approx. 100 Ω
open drain
(Pulled up to +5 V
by 10 kΩ)
Outputs LO in Operate status.
Outputs HI in Standby or Suspend status.
OPERATE
SUSPEND IN
*2
Input TTL negative
level
Approx. 10 kΩ Sets Standby when the signal level
changes from LO to HI.
Sets Operate when the signal level
changes from HI to LO.
*1, *2: The same terminal is used by switching respectively.
*3: The SYNC OUT signal is not output for functions other than the continuous function in the DC source mode.
*4: When the step time is less than 0.1 sec, the output timing becomes 10 ms.
