6146/6156 DC Voltage/Current Generators Operation Manual
6. PERFORMANCE TEST
6-1
6. PERFORMANCE TEST
This chapter describes the methods for checking whether the 6146/6156 operates in the specified accuracy.
6.1 Measuring Instruments Necessary for Performance Test
Use a measuring instrument for the performance test which meets the specifications shown in Table 7-1,
"Accuracies and Cables Necessary for Calibration."
6.2 Connections
The connections required for the performance test are the same as shown in Figure 7-1, "Connections for Cal-
ibration."
6.3 Test Method
Execute the performance test under the following conditions in a location free of dust, vibration, noise or
other adverse conditions:
Temperature: 23 ± 5°C
Relative humidity: 70% or lower
Warm-up: 30 minutes or longer
• Self-test, display, key, and buzzer tests
1. Select MENU and SYS and refer to Section 4.2.12, "Self Test" to execute.
NOTE: If an error occurs during the test, refer to Section 4.2.12, "Self Test" to verify
the content of the error.
• Voltage source/limiter test
1. Connect the 6146/6156 and DMM (Digital Multimeter) as shown in Figure 7-1
(a).
2. Set DMM to DCV, auto range and integration time of 10 PLC or longer.
3. Set the 6146/6156 to the DC source mode.
4. Select voltage source.
With ZERO and ± Full Scale generated in the 300 mV range to 30 V range, verify
that the difference between the source value and the DMM measured value is
within the accuracy described in Chapter 8, "SPECIFICATIONS."
5. Select current source and set to the 3 mA range.
With ZERO (minimum value: 1 V) and ± Full Scale of the voltage limit set, verify
that the difference between the setting value and the DMM measured value is
within the accuracy described in Chapter 8, "SPECIFICATIONS."
To Next Page
