6146/6156 DC Voltage/Current Generators Operation Manual
2.2.3 Menu Operation
2-23
2.2.3.2 Menu Structure and Parameter Setting
The parameter type indicates the setting method at the Input/Run level.
SENSE Remote sense
2W/4W
Select
LMT.HL Simultaneous setting of HI/LO limit values
OFF/ON
Select
AUTO Source value setting auto range
OFF/ON
Select
POL Polarity setting mode (unipolar/bipolar)
UN.POL/BI.POL
Select
SUS.Z Suspend status
HI.Z/LO.Z
Select
CO.FIX Count fix function
OFF/ON
Select
SBY.MD Standby mode
0/1
Select
OPR.HD Operate hold function
OFF/ON
Select
MENU
SOURC
Source
(a)
Category level
Select level Input/Run level
SWEEP
Sweep
Parameter type
START Sweep start value Numeric
VS IS Thermal EMF
6146 +00.000 mV to
±32.000 V
+0.0000 mA to
±220.00 mA
-
6156 +00.0000 mV to
±32.0000 V
+0.00000 mA to
±220.000 mA
-200.0°C to
+1820.0°C
STOP Sweep stop value Numeric
VS IS Thermal EMF
6146 +00.000 mV to
±32.000 V
+0.0000 mA to
±220.00 mA
-
6156 +00.0000 mV to
±32.0000 V
+0.00000 mA to
±220.000 mA
-200.0°C to
+1820.0°C
STEP Sweep step value Numeric
VS IS Thermal EMF
6146 +00.000 mV to
±32.000 V
+0.0000 mA to
±220.00 mA
-
6156 +00.0000 mV to
±32.0000 V
+0.00000 mA to
±220.000 mA
-200.0°C to
+1820.0°C
BIAS Sweep bias value Numeric
VS IS Thermal EMF
6146 +00.000 mV to
±32.000 V
+0.0000 mA to
±220.00 mA
-
6156 +00.0000 mV to
±32.0000 V
+0.00000 mA to
±220.000 mA
-200.0°C to
+1820.0°C
RTB Returns to the bias value when sweep stops.
OFF/ON
Select
*Thermal EMF: thermal electromotive force
