ADCMT 6156 User Manual

6146/6156 DC Voltage/Current Generators Operation Manual
4.2.12 Self Test
4-34
2. Self-test execution by manual operation or turning the power ON
When executing the self test by manual operation, select MENU, SYS and TEST in that order and
press ENTER.
Figure 4-19 Self-test Operation
3. Key test execution
When executing the key test, select MENU, SYS and P/KEY in that order and press ENTER. Press-
ing any key displays its name on the panel. Press EXIT to terminate the key test.
Power ON
Revision display
Passed
Failed
Self test in progress
Verify the error detected
Passed (no error)
Displayed in accordance
with the key pressed
R-INC: Rotate the rotary key clockwise.
R-DEC: Rotate the rotary key
counterclockwise.
• All the pan-
els light up
(including
indicators).
• Buzzing
approx. 1
second
