6146/6156 DC Voltage/Current Generators Operation Manual
2.2.3 Menu Operation
2-20
The polarity of the HI limit value is fixed positive, and that of the LO limit value
is fixed negative. Their polarities cannot be changed.
6. Press LIMIT or EXIT to exit the limit value setting screen and return to the
HOME screen.
2.2.3 Menu Operation
The 6146/6156 functions and parameters are set on a hierarchical menu.
The menu is a 3-level hierarchical structure.
Level 1 Category level Select a category.
Level 2 Select level Select a parameter to set within the category.
Level 3 Input/Run level Input or select a set value.
Figure 2-13 shows an overview of the menu operations.
Cursor (blinking)
Half-brightness
