6146/6156 DC Voltage/Current Generators Operation Manual
5.3.3 Setting GPIB
5-11
• Setting Listen Only
Operation Character display area
1. 6146
Press MENU and select ..7..I/F with , or .
MENU
..7.. I/F
6156
Press MENU and select ..8..I/F with , or .
MENU
..8.. I/F
2.
Enter the Select level with .
(Currently set I/F)
I/F
USB BUS
(If the GPIB interface is currently set, start from Step 6.)
3.
Enter the Input/Run level with .
BUS
USB
4.
Select GPIB with , , or .
BUS
GPIB
5. Press ENTER to confirm the setting. (The menu reverts to the
Select level.)
(Currently set GPIB address)
I/F
GPIB BUS
6.
Select L.Only (Listen Only) with , or .
(Currently set status)
I/F
OFF L.Only
7.
Enter the Input/Run level with .
L.Only
OFF
8.
Select ON or OFF with , or .
L.Only
ON
9. Press ENTER to confirm the setting. (The menu reverts to the
Select level.)
(Currently set status)
I/F
ON L.Only
10. Press EXIT to exit the menu.
