6146/6156 DC Voltage/Current Generators Operation Manual
8.1 Voltage/Current Source
8-4
• 6146/6156
Maximum load/output resistance: 3 V/30 V range: output resistance in 4-wire connection
Other ranges: output resistance in 2-wire connection
Output noise: Voltage source: within the range from no-load to maximum load
Current source: at load resistance of 1 kΩ
Settling time: Time to settle to the final value ± 0.1% when varying from zero to the full scale.
Setting conditions: Source values and limiter values are full-scale settings.
Load conditions: Pure resistive load and 200 pF max. load capacitance
Overshoot: ±0.1% max., pure resistive load, at end of standard cable
Line regulation: ±0.003% of range or less
Load regulation: ±0.003 % of range or less (in 4-wire connection with maximum load)
(excluding the 30 mV and 300 mV ranges)
Maximum load capacitance: Maximum value that does not oscillate in voltage source or voltage limiter
Voltage source/voltage limiter: 1000 μF
Range Maximum load Output resistance
Voltage source 30 mV 1.5 μA (*1) Approx. 2 Ω
300 mV 15 μA (*1)
3 V ± 220 mA 2 mΩ or less
30 V 2 mΩ or less
Current source 3 mA Output compliance voltage: ±32 V 500 MΩ or higher
30 mA 320 MΩ or higher
200 mA 32 MΩ or higher
*1 : Load that gives an error of 0.01% of the range
Range
Low frequency noise High frequency noise
DC to 100Hz DC to 10kHz DC to 20MHz
Voltage source 30 mV 5 μV10 μV3 mV
[Vp-p] 300 mV 15 μV30 μV
3 V 30 μV120 μV
30 V 100 μV300 μV
Current source 3 mA 30 nA 100 nA 6 μA
[Ap-p] 30 mA 300 nA 400 nA
200 mA 3 μA3 μA
Range Settling time
Voltage source 30 mV 10 ms or less
300 mV
3 V
30 V
Current source 3 mA 10 ms or less
30 mA
200 mA
