6243/44 DC Voltage Current Source/Monitor Operation Manual
6.4.2 Data Output Format in the TR6143 Mode (Talker)
6-19
(5) Operation status
When operation status output is specified by OM4, the operation status is output in the following for-
mat.
(a) Header (ON/OFF possible by S5/S4 command)
(b) Data number
(c) Block delimiter
• Data number (8-bit binary data output)
SS
(a) (b) (c)
bit
Decimal
number
Condition to be set Condition to be cleared
b7 128 Limiter detection (LMT) Clearing the limiter
b6 64 Oscillation detection (OSC) Clearing the oscillation detection
b5 32 Overheating detection (OVH) When the operation starts.
b4 16 Overload detection (OVL) When the operation starts.
b3 8 None None
b2 4 None None
b1 2 During sweep Sweep stop
b0 1 Operating status Standby
To Next Page
