A.2 Error Message List
A-4
Self-test +350 IM 32 A ZERO 261 IM 32 A ZERO test error.
+351 IM 320 A ZERO IM 32 A ZERO test error.
+352 IM 3.2 mA ZERO IM 3.2 mA ZERO test error.
+353 IM 32 mA ZERO IM 32 mA ZERO test error.
+354 IM 320 mA ZERO IM 320 mA ZERO test error.
+355 IM 2 A ZERO IM 2 A ZERO test error (6243).
+355 IM 3.2 A ZERO IM 3.2 mA ZERO test error (6244)
+356 IM CMV IM CMV test error.
+357 OVL Check OVL detection check error
+358 IM 10 A ZERO IM 10 A ZERO test error
Hardware failure +360 Fan Stop Cooling fan failure
+361 Over Heat Internal circuit overheat
+362 Source Unit The source unit malfunctions
Execution error +201 Calibration Calibration error
+210 Sweep Data>5000 (Linear) The number of steps has exceeded 5000.
+211 |Start|>|Stop| (Log) In a log sweep, the starting value is greater than the stop value.
+212 Start, Stop Polarity (Log) In a log sweep, the starting and stopping polarities are different.
+213 Power Over Source limiter setting exceeds the output range.
+214 Start, Stop =0 (Log) In a log sweep, the staring or stopping value is 0.
+215 Step =0 (Linear) The step value for a linear sweep is 0.
+216
Start 0 at FixRange (Log)
For a log sweep, the fix range starting value is 0.
Command error +101 Command Execution GPIB command execution error.
GPIB argument range error.
+102 Command Syntax GPIB command syntax error
An unrecognized command is received.
Source / measurement
message
None OSC/osc Oscillation measurement / oscillations detected.
None RP/rp Reversed polarity source measurement / reversed polarity
source connections detected
None LM/lm Limit measurement / Limiter detected
None Over Range The measurement value has exceeded the range.
None Over Load Over load
None HI Comparative calculation result HI
None GO Comparative calculation result GO
None LO Comparative calculation result LO
External single line
signal test
None Failed 01,03,05,07,09,11,13,15 SYNC OUT or TRIGGER IN malfunction
None Failed 02,03,06,07,10,11,14,15 OPERATE OUT or BUSY IN malfunction
None Failed 04 to 07, 12 to 15 BUSY OUT or OPERATE IN malfunction
None Failed 08 to 15 COMPLETE OUT or OPERATE IN malfunction
Table A-2 Error Message List (2 of 2)
Category
Error
No.
Display message Description
