Mounting the Robot
Adept Cobra i600/i800 Robot User’s Guide, Rev G 21
NOTE: The base casting of the robot is aluminum and can easily be dented
if bumped against a harder surface. Verify that the robot is mounted
squarely (will not rock back and forth) before tightening the mounting
bolts.
6. Install the user-supplied mounting bolts and washers. Tighten the bolts to the
torque specified in Table 2-2.
NOTE: Check the tightness of the mounting bolts one week after initial
installation, and then recheck every 6 months. See Chapter 5 for periodic
maintenance.
WARNING: The center of mass of the robot may cause the
robot to fall over if the robot is not secured with the
mounting bolts.
Table 2-2. Mounting Bolt Torque Specifications
Standard Size Specification Torque
Metric M12 x P1.75 ISO Property Class 8.8 85 N·m
SAE 7/16-14 UNC SAE Grade 5 63 lbf·ft
