520
ADOBE ILLUSTRATOR CS2
User Guide
If a graph uses more than one graph type, you may want one set of data along the right axis and the other set of data
along the left axis. In this way, each axis measures different data.
Note: If you use stacked column graphs with other graph types, be sure to use the same axis for all sets of data that are
representedbystacked column graphs.Ifsomesetsofdatause theright axiswhile others usethe left,the column heights
may be misleading or may overlap.
To select parts of a graph
1 Select the Group Selection tool
2 Click the legend of the columns you want to select.
3 Without moving the Group Selection tool pointer from the legend, click again. All of the columns grouped with
the legend are selected.
You can also select a group by clicking one of its parts, clicking again to select columns grouped with it, and clicking
a third time to select the legend. Each click adds another layer of grouped objects to the selection, beginning with
the next group up in the hierarchy. You can click as many times as the number of groups to add to a selection.
4 To deselect part of a selected group, select the Direct Selection tool , and Shift-click the object.
To format the text in a graph
Illustrator uses a default font and font size when generating text for the graph’s labels and legend. However, you can
easily change the formatting of type to add visual interest to your graph.
1 Select the Group Selection tool
2 Click once to select the baseline of the type you want to change; click twice to select all of the type.
3 Change the type attributes as desired.
Adding pictures and symbols to graphs
About graph designs
Yo u u s e graph designs to add illustrations to columns and markers. Graph designs can be simple drawings, logos, or
other symbols representing values in a graph; they can also be complex objects that contain patterns and guide
objects. Illustrator comes with a variety of preset graph designs. In addition, you can create new graph designs and
store them in the Graph Design dialog box.
You can apply graph design to columns in several ways:
• A vertically scaled design is stretched or compressed vertically. Its width does not change.
• A uniformly scaled design is scaled both vertically and horizontally. The horizontal spacing of the designs is not
adjusted for the different widths.
.
.
