iFT Series Hardware Installation Manual ADPRO
14 27817_08
Caution!
l Beforeinstallingharddisks,stopthedevice.Switchitoffandunplugthepowercord.
l Takeallnecessaryprecautionstopreventstaticdischargesthatmaydamagethedevice:usean
anti-staticwristband,ananti-staticmat…
l Theprocedurebelowassumesthatyouareusinganew disk,or,incaseofauseddisk,thatyou
willformat the used disk anderaseallrecordingsonit.Ifyouwanttoinstallausedharddisk
whilekeepingtherecordingsonit,followtheinstructionsintheTechTipRecovering Recordings
from Used HDDs(29160).
Toinstallthefirstharddisk,proceedasfollows:
1. Stopthedevice,switchoffthepowersupply,andthenremovethetopcover:unscrew2screwsatthefront,
4atthetop,and3attheback.

2. Fixtheharddisktothebottomofthecasing.
Caution!
Ifyoutiltthecasing,restitcarefullyonthesides,butnotontheback.Youmaydamagethe
connectorsifyoudo.
Dependingontheavailableholesinthecasingandtheharddisk,thefollowingoptionsexist:

o
Casingwith6 screw holes inthebottom:usethefirst4holes,ortheouter4holeswith4diskscrews
(#17434080):

o
Oldcasingwith4 screw holes inthebottom:use4oronly2diskscrews(#17434080):
