14 Connecting PIR Detectors
14.1 Required PIR Firmware
ForcorrectPIRalarmprocessing,aminimalPIRfirmwareversion2.00isrequired.Previousfirmwareversions
alsoworkwithRS-485communication,butdonotsupportallfeatures(e.g.alarmmanagement).
14.2 Connecting PIR Detectors
ToconnectPIRdetectorstotheXOdevice,youhavethefollowingoptions:
Connection method Max. no. of PIR detectors
RS-485cableconnecteddirectlytotheMIOcardoftheXOdevice 32ontheRS-485bus
ViaaUSB-to-RS-4858-channeldistributionunit,connectedtoaUSBport
ontheXOdevice
32ontheRS-485bus
ViaaUSB-to-serial-portRS-485converter,connectedtoaUSBportonthe
XOdevice
32ontheRS-485bus
ViatheIFM-485-STinterfacemodule,connectedtoaUSBportontheXO
device
32ontheRS-485bus
ViaIPmodules,connectingthePIRdetectorsviathelocalnetworktothe
XOdevice(noRS-485busrequired)
34;withfirmwareversion
XOa3.02.0001orabove
Youcanconnectmaximum32PIRdetectorsonanRS-485bus.However,youcancombineanRS-485busand
IPmodulestoconnectmorePIRdetectorstotheXOdevice.
ThemaximumnumberofPIRdetectorsonanXOdeviceis34(requiresminimumfirmwareversion
XOa3.02.0001).
TheXOclientwillindicatehoweachPIRdetectorisconnected:overRS-485(SER)oroverIP(ETH).
YoucanconnectaPIRdetectortoonlyoneXOdevice.
Note
YouneedaPIR-HLIapplicationlicensetoenablethePIRdetectors.UseXchangetoinstallthe
licenseontheXOdevice.Formoreinformation,seetheXchange Tool User Manual(27816).
14.3 PIR Address Range
Regardlessoftheconnectionmethod,PIRdetectoraddressesmustbeinthefollowingranges:
l FirmwareversionXOa3.02.0001andabove:1–34.TheXOdevicewillnotdiscoverPIRdetectorswith
addressesabove34.
l FirmwareversionsbelowXOa3.02.0001:1–32.TheXOdevicewillnotdiscoverPIRdetectorswithaddresses
above32.
Furthermore,eachPIRdetectormusthaveauniqueaddress,regardlessoftheconnectionmethod(RS-485
orIP).ForinstructionsonsettingPIRdetectoraddresses,seetheADPRO PRO E PIR System Setup Manual
(26571).
14.4 Direct Connection to the MIO Card
ConnectthePIRdetector(s)totheXOdevicebyconnectingtheRS-485cableofthePIRclosesttotheXO
devicetotheMIOcardoftheXOdevice.Youcanconnectupto32PIRdetectorsincascadeontheRS-485bus.
