A PS/2:keyboardormouse G /dev/ttyU4(USB)
B DVI-I:monitor H /dev/ttyU3(USB)
C eth0:networkforXOdevice I DisplayPort:monitor
D eth1:networkforIPcameras J /dev/ttyU1(USB):modem
E Audiolinein K /dev/ttyU2(USB)
F Audiolineout 
Note
TheXOdevicedoesnotsupporttheUSB3portsonthePH10LUmotherboard.
5.4 Replacing the Motherboard
Donotreplacethemotherboardinthefield.Ifthemotherboardneedsreplacing,sendthedevicebacktoyour
supplier.Rememberthatthesystemlicensesislinkedtothemotherboard.Ifyoureplacethemotherboard,the
systemmaynotrecognisethesystemlicenseandwillnotbefunctional.
5.5 Replacing the Motherboard Battery
Itmaybenecessarytoreplacethemotherboardbatteryaftersometime.Forfurtherinstructions,seethe
technicaldocumentationofthemotherboard.
