8 XO I/O Interface USB Modules
8.1 About the XO I/O Interface USB Modules
FirmwareversionXO4.0andabovesupportstheXOI/OInterfaceUSBmodulesforextrainputsandoutputs.
ThesemodulescontainsetsofMainI/OandExtensionI/Ocards(NextGeneration)thatyoucanconnecttoyour
XOdeviceviaUSB.
XOI/OInterfaceUSBmodule: Rearview,singlemodule:
TheXOI/OInterfaceUSBmodulesfunctionjustlikeinternalMIO/EIONextGenerationcards,butwiththe
followingrestrictions:
l TherearenoAUDIOOUTandAUDIOGNDoutputs:ifyouwanttouseaVM22Aaudioswitcher,youhaveto
connectittothebuilt-inMIOcardinstead.ItispossibletouseaVM22Eswitcher.
l YoucanaddonlyonesetofMIO/EIOcardstoyourdevice=asingleXOI/OInterfaceUSBmodule.Youthen
havetwoMIOcardsandoneEIOcardintotal.Youcannotusethedoublemodule.
Youhavetomapthemodulestothecorrectcardset(MIO-1orMIO-2)usingthehardware configuration tool.If
not,theXOdevicewillnotdiscoverthecardsandyouwillnotbeabletousetheinputs/outputs.
Furthermore,ifyouareusingadaptersontheUSBportsofyourXOdevice(toconnecttoPIRdetectorsorfor
PTZcontrolofanaloguecameras),youalsohavetomapthese'devices'usingthehardwareconfigurationtool.If
thesystemdetectsamismatchbetweentheitemsconfiguredinthehardwareconfigurationtoolandthehardware
thatthesystemhasdetected(eithermoreorlessthanconfigured),thesystemwillactivatesysteminput0002–
[SYST]–HWCFGMISMATCH.
Fordetailedinformation,seetheXO I/O Interface USB Module Technical Manual (32688).
Note
Althoughitistechnicallypossibletodisableanexisting,built-inMIO/EIOcardinthehardware
configurationtool,anduseanexternalmoduleinstead,Honeywellrecommendstokeepandusethe
built-incards.Ifyoudisableabuilt-inMIOcard,youhavetoswitchoffthebuzzerandwatchdog
features,orthesystemwillbeepcontinuously.Switchingoffthebuzzerandwatchdogseriously
reducesthesystem'sreliabilityandsecurity.
Caution!
UsingtheXOI/OInterfaceUSBmoduleschangestheinternalUSBportnumberingontheXOdevice.
Thedefaultnumberingasindicatedinthehardwaremanualsnolongerapplies.Ifyouhaveanyother
devicesthanXOI/OInterfaceUSBmodulesontheUSBportsofyourXOdevice,youalsomust
remapthesedevicesinthehardwareconfigurationtool,andyoumustadjusttheserialportsettingsin
theXOclient.
WhenyoustopusingXOI/OInterfaceUSBmodulesontheXOdevice,youhavetoresetthe
USBportnumberinginthehardwareconfigurationtooltoreturntothedefaultUSBportnumbers.
