Hybrid Standalone NVR User Guide 3 Local Menu Operations
Main PTZ Control Panel
The Pan/Tilt/Zoom main control interface appears. Here you can set the following items:
• Speed
• Direction Keys
• SIT - 3D Intelligent Positioning Key
• Zoom, Focus, Iris (to adjust brightness)
• PTZ Trace
Figure 3-62
3.6.4.4 Speed
Input a speed value using the numeric keypad. Select from 1-8, with 8 the fastest.
3.6.4.5 Direction Keys
Click one of the eight the direction arrows to adjust the Pan/Tilt/Zoom (PTZ) position. The camera
moves accordingly. Note that there are only four direction arrows on the NVR front panel.
3.6.4.6 3D Intelligent Positioning Key
The PTZ function supports 3D intelligent positioning, which enables you to use the mouse to position
the viewing area and automatically adjust the zoom, focus and iris settings.
To use 3D intelligent positioning:
1. Locate and click the button labeled SIT in the center of the eight direction arrows.
The system reverts to the single screen mode.
2. Drag the mouse in the screen to adjust the section size. PTZ initiates automatically to adjust
to the dragged area. The dragged zone supports 4X to 16X speeds. The smaller the zone you
drag, the higher the speed.
Figure 3-63
NVR4200 Series User Guide
94
