Hybrid Standalone NVR User Guide 3 Local Menu Operations
3.6.4.7 Zoom, Focus, Iris
Click and to modify the Zoom, Focus and Iris settings.
key
key
key
key
Zoom
Zoom in
Zoom out
Focus
Focus near
Focus far
Iris
Close
Open
Click
to expand the menu for access to Preset, Tour, Pattern and Scan functions.
Figure 3-64
Refer to the following table for details. Please note that the dialog may vary with different protocols.
The button is grayed out and cannot be selected if the function is not available.
Right mouse click or click the ESC button on the front panel to return to the main PTZ control
interface.
Icon Function Icon Function
Preset
Flip
Tour
Reset
Pattern
Aux
Scan
Aux on / off
Rotate
Go to menu
NVR4200 Series User Guide
95
