Hybrid Standalone NVR User Guide 4 Web Service
PTZ Type
There are two options: Local or Remote. Select the Remote type if you are connecting to the network
PTZ.
Protocol
Select the corresponding dome protocol such as PELCO D.
Address
Set the corresponding PTZ camera address. The default value is 1.
Note that your setup here must comply with your PTZ camera address.
Baud Rate
Select the dome baud rate. Default setup is 9600.
Data Bit
Default setup is 8. Set this according to the PTZ camera dial switch setup.
Stop bit
Default setup is 1. Set this according to the PTZ camera dial switch setup.
Parity
Default setup is none. Set this according to the dial switch setup on the PTZ camera.
NVR4200 Series User Guide
211
