Hybrid Standalone NVR User Guide 3 Local Menu Operations
a. Left mouse-click and drag it to set the desired region. If the area is already blue (armed),
dragging the mouse sets the cells clear (disarmed). If the area is already clear (disarmed),
dragging the mouse sets the cells armed (blue).
or
b. Press the Fn button on the front panel to switch between the armed mode and disarmed
modes. Use the arrow keys to apply that format to the grid cell.
6. After setting the zone, exit and return to the Detect zone setup screen, using one of the
following methods:
a. Right mouse-click
or
b. Press the Enter button on the front panel
7. Set the Sensitivity level 1-6, where 6 is the most sensitive. The default is 3.
8. Select the Test button. A screen appears as in Figure 3-31. The system only displays the
motion detect status of the blue area. The red flashing area shows motion has been detected
in this area.
Figure 3-31
9. In the Period area, select the Setup button. The Setup dialog opens for setting the motion
detection period.
NVR4200 Series User Guide
63
