AIMB-584 User Manual 68
Backlight Signal Control [ PWM ]
Switch Backlight Signal Control for PWM or LINEAR.
LVDS/eDP Select [ LVDS ]
Select the Active LFP Configuration.
Note! LVDS and eDP co-layout designed on AIMB-584, and the default setting
in BIOS and HW both are LVDS. If customer would like to active eDP
function, then both of HW and BIOS need to be modified.
