67 AIMB-584 User Manual
Chapter 3 BIOS Operation
Here is 2-3 displays combination table and all of these combinations are verified and
tested properly already.
LVDS Panel Type [ Disabled ]
Note! The triple display can only working PASS under Windows 7 and 8, the
2nd and 3rd display can not work under DOS.
Display Combination List BIOS DOS WES 7
Single Display
CRT PASS PASS PASS
DVI PASS PASS PASS
DP PASS PASS PASS
EDP PASS PASS PASS
LVDS PASS PASS PASS
Dual Display
CRT+DVI NA NA PASS
CRT+LVDS NA NA PASS
CRT+DP NA NA PASS
CRT+EDP NA NA PASS
DVI+LVDS NA NA PASS
DVI+DP NA NA PASS
DVI+EDP NA NA PASS
LVDS+DP NA NA PASS
LVDS+EDP NA NA PASS
Triple Display
DP+LVDS+DVI NA NA PASS
CRT+LVDS+DVI NA NA PASS
CRT+DP+LVDS NA NA PASS
DP+EDP+DVI NA NA PASS
CRT+EDP+DVI NA NA PASS
CRT+DP+EDP NA NA PASS
CRT+DP+DVI NA NA PASS
Note! When you enable LVDS type, customers can choose different resolution
settings from the table. Default resolution setting is "800 x 600 18-bit".
