Software Console
The software console is displayed on the NX workstation.
On a configuration with tube head display, the software console is displayed
on the tube head display as well. The arrangement and availability of the
controls may be slightly different.
Table 16: Navigation
Navigation button Software console screen
Examination overview
Generator controls
X-ray modality controls
System messages
Topics:
• Action buttons
• Planned exposures
• DR detector and X-ray tube head alignment
• Live camera image
• X-ray image preview screen
• X-ray modality status frame
• Generator controls
• X-ray modality controls
• System messages screen
