Manual collimator technical data
Model R108 F
Manufacturer Ralco
Via dei Tigli 13/G
20853 Biassono (MB), Italy
Collimation Manual with internal light source, multi-
layer, squared field, laser field to deter-
mine the SID at 1 m.
Assembly plan from focus 80 mm (3.14")
Coverage of the field at 100cm
SID
minimum 0 cm x 0 cm
maximum 43 cm x 43 cm
Lighting source Clusters of high-brightness LED power
Lamp lighting time 30 s
Light intensity (IEC 60601-2-54) > 160 lux
Minimum contrast ratio (IEC
60601-2-54)
4:1
Focal distance measurement Retractable tape measure (maximum ex-
tension 3 m)
Maximum radiation leakage 150 kVp - 4mA
Inherent filtration 2 mm equivalent Al at 75kV
Additional filtration
Manual selection
• 0 mm Al
• 1 mm Al + 0.1 mm Cu
• 1 mm Al + 0.2 mm Cu
• 2 mm Al
Rotation ± 120°
Weight 5.5 kg
178 | DR 100s | Product Information
0411D EN 20220627 1040
