Led beacon light
Figure 19: Led beacon light (green)
Table 4: Led beacon light
Color Meaning
Off The system is not ready for making an exposure.
Green The wireless DR Detector and the X-ray generator are ready for mak-
ing an exposure.
Yellow X-ray radiation is ongoing.
40 | DR 100s | Introduction
0411D EN 20220627 1040
