X-ray group (32 kW configuration)
Table 38: X-ray specifications
Nominal power (IEC 60601-1) 32 kW @ 100 kV, 320 mA
kV values 40 - 125 kV at steps of 1 kV
mA values @115/230Vac
70 - 320 mA
(automatically associated to kV)
mAs values @115/230Vac
0.1 - 320 mAs
(with increases of 12.5%)
Exposure times @115/230Vac
0.001 - 3 s (DR mode)
0.001 - 10 s (CR mode)
(according to mAs)
Table 39: Accuracy (IEC 60601-2-54)
kV ±5%
mA @115/230Vac ±20%
mAs ±(10% + 0.2 mAs)
Time ±(10% + 0.1 ms)
Table 40: Equivalent filtration @75 kV
Filtration 1.4 mm Al
Collimator 2 mm Al
Total filtration 3.4 mm Al
Additional filtration of DAP meter (optional) 0.3 mm Al
Total filtration with DAP meter (optional) 3.7 mm Al
DR 100s | Product Information | 183
0411D EN 20220627 1040
