Typical exposure parameters
The default X-ray exposure parameters for each exposure type can be
customized. The device is delivered with a set of X-ray exposure parameters
that are intended as a guideline. The default X-ray exposure parameters are
only starting points that can be replaced by more specific X-ray exposure
parameters developed by the operator.
In the following table the dose values are expressed in µGym
2
(Dose Area
Product), the exposures are set with standard values for clinical investigations
on the patient and performed with the X-ray tube with a SID of 100 cm and
without grid.
The dose measurement has been performed according to IEC 60601-1-3 §
5.2.4.2 with the dosimetric chamber supplied with the equipment and the
collimator completely open.
Table 44: Anatomic group for examinations of the body
Anatomic program Focus kV mAs µGym
2
Chest AP Large 110 2 17.83
Abdomen AP Large 81 16 76.37
Abdomen LAT Large 90 20 118.94
Chest LAT Large 110 4 34.63
Sternum Small 85 4 22.84
Ribs Small 70 6.3 24.12
Table 45: Anatomic group for examinations of the skull/spine
Anatomic program Focus kV mAs µGym
2
Skull AP Small 77 10 46.71
Thora. Spine AP Small 77 20 93.97
Lumbar Spine AP Large 81 20 104.10
Cervical Spine Small 66 8 27.07
Thora, Spine LAT Large 81 16 76.39
Lumbar Spine LAT Large 90 20 118.84
DR 100s | Product Information | 189
0411D EN 20220627 1040
