AGFA DR 100s - Automatic Collimator

Automatic Collimator
1
2
3
5
4
1.
Touchscreen display
2.
Longitudinal collimation
3.
Rails to insert a DAP meter or a filter.
4.
Measurement tape to measure the source image distance (SID).
The measurement tape is at the rear side of the collimator.
5.
Transversal collimation
Buttons to switch on the light field and laser light are available on the
software console, on the tube head display and on the exposure button.
