Table 41: Maximum settable mAs
focus small large small large
exposure
time
1 s 3 s 3 s 1 s
minimum
mAs
0.1 0.63 0.1 0.63
kV maximum
mAs
maximum
mAs
maximum
mAs
maximum
mAs
40 120 250 300 310
50 120 250 300 310
60 120 250 300 310
70 100 250 210 280
80 100 250 210 280
90 80 250 210 200
100 80 250 150 200
110 60 210 150 150
125 60 2100 150 150
Table 42: Monobloc
Model HF1 R/7 ORB
Maximum power (100 kV - 400 mA) 32 kW
Maximum voltage to the tube 125 kV
Maximum current to the tube 350 mA
Ripple to the maximum power < 2%
Rise time to the max. power < 1 ms
Thermal safety 60 °C ± 5° C
Oil volume compensation lung 0.20 dm
3
Maximum thermal capacity 600 kJ
Total thermal safety 900 kJ
Maximum continuous heat dissipation 60 W
Minimum inherent filtration @75 kV 1.4 mm Al
Half-value layer @75 kV 2 mm Al
184 | DR 100s | Product Information
0411D EN 20220627 1040
