7. If the position of the patient is adjusted, repeat the measurement.
a) Press the reset button.
Figure 51: Reset button
The readouts for the measured SID and patient size are cleared.
b) Repeat the above steps to perform a new measurement.
After a measurement is performed, guidance for dose adaptation is indicated
on the patient size buttons. The measured patient size is not updated when
repositioning the patient or the X-ray tube.
The live camera button returns the live camera image. The readouts for
measured SID and patient size are retained, but no more area’s can be added
to the measurment. By touching the live camera image, the readouts are
cleared and a new measurement is started.
Figure 52: Live camera button
DR 100s | Software Console | 111
0411D EN 20220627 1040
