Dimensions (in secured position)
width x length x height
576 x 1290 x 1364 mm
Handle height
(adjustable by service)
940 - 960 mm
Weight 470 kg
(without DR detector)
Focus-floor distance (Z-axis)
675 mm - 2051 mm
Maximum height
2185 mm
Telescopic arm extension range 360 mm
front: 750 - 1110 mm
lateral: 586 - 946 mm
Rotation of the X-ray tube assembly
around the arm axis (α swivel)
± 90°
Rotation of the X-ray tube assembly
around the column axis (β swivel)
± 320° from secured position
Rotation of the X-ray tube assembly
around its axis (γ swivel)
110° (+90° ahead, -20° back)
Movement motorized
The speed is proportional to the force
impressed on the transport handle.
Movement speed forward, in secured position: 0 - 1.4
m/s
forward, in working position: 0 - 0.7
m/s
backward: 0 - 0.7 m/s
Slope of the floor while driving maximum 10° (18%)
Slope of the floor while parking
(brakes must not be released)
maximum 10° (18%)
Height of surmountable obstacles maximum 40 mm
Wheels diameter front: 125 mm (damped)
rear: 300 mm
172 | DR 100s | Product Information
0411D EN 20220627 1040
