Name Color Meaning
BATT Battery charge level is low. The battery of the wireless ex-
posure button must be replaced as soon as possible.
Battery charge level is very low. The battery of the wireless
exposure button must be replaced immediately.
LINK The wireless exposure button is wirelessly connected to the
holder and is not in sleep mode.
TOUCH The touch sensor has been set to enabled.
BUZZ The take-away prevention function has been set to enabled.
SW1 The exposure button is pressed down to step 1: preparation
of the X-ray tube.
SW2 The wireless exposure button is pressed down to step 2: ex-
posure.
Table 6: Led beacon light on the wireless exposure button
Color Meaning
Green The wireless DR Detector and the X-ray generator are ready for mak-
ing an exposure.
Yellow X-ray radiation is ongoing.
Related Links
Replacing the battery of the wireless exposure button on page 134
DR 100s | Introduction | 43
0411D EN 20220627 1040
