1
2
3
4
5
Figure 25: Interfaces for registering the DR detector or connecting to the
network
Table 8: Interfaces for registering the DR detector or connecting to the
network
(1)
USB connector.
(2)
Network connector to connect the Registration Cable for
registering a DR Detector.
(3)
Network connector to connect the NX workstation to the
hospital network.
(4)
IR Data Communication Unit (optional).
(5)
Emergency stop button.
DR 100s | Introduction | 49
0411D EN 20220627 1040
