192 1290 Infinity Quaternary Pump User Manual
9 Maintenance
Replacing Parts of the Inline Filter
1
Remove the capillaries from the Multi Purpose Valve to
the inline filter.
2 Remove the inline filter from the clamp attached to the
Multi Purpose Valve.
3 Use two 5/16 wrenches for opening the inline filter. 4 Replace the filter frit and reassemble the inline filter.
Inline filter
Clamp
Filter frit
