Agilent Technologies 34410A Service Guide

34410A/11A/L4411A Service Guide 83
Calibration Procedures 3
Valid Gain and Flatness Adjustment Input Values. Gain adjustment can be
accomplished using the following input values.
[1] Valid frequencies are nominal frequencies ±1%.
[2] 100 Vac flatness adjustment performed at 50 V
±10%.
[3] Actual limit is 300 Vac, but results degrade above 219 Vac.
Function Range Valid Amplitude Input
Values
DC Volts 100 mV to 100 V
1000 V
0.9 to 1.1 x Full Scale
450 V to 550 V
DC Current 100 μA to 1 A 0.9 to 1.1 x Full Scale
3 A 1.8 A to 2.2 A
Ohms 2W, Ohms 4W 100 Ω to 10 MΩ 0.9 to 1.1 x Full Scale
Frequency Any Input > 100 mV rms,
990 Hz to 110 kHz
AC Current (rms)
[1]
100 μA to 1 A 0.9 to 1.1 x Full Scale
3 A 1.8 A to 2.2 A
AC Volts (rms)
[1]
100 mV to 100 V
[2]
0.9 to 1.1 x Full Scale
750 V 189 V to 219 V
[3]
