84 34410A/11A/L4411A Service Guide
3 Calibration Procedures
DC Voltage Gain Calibration Procedure
Review the “Test Considerations” on page 63 and “Gain Adjustment
Considerations” on page 82 sections before beginning this procedure.
Configuration: DC Voltage
1 Configure each function and range shown in the adjustment table
below.
2 Apply the input signal shown in the “Input” column of the table.
3 Enter the actual applied input voltage
(see “Entering Adjustment Values” on page 78).
a Successful completion of each adjustment value is indicated by the
message CAL SUCCEEDED flashing in the display.
b If a problem is encountered, the display will flash the message
CAL FAILED. Check the input value, range, function, and entered
adjustment value to correct the problem and repeat the adjustment
step.
4 Repeat steps 1 through 3 for each gain adjustment point shown in the
table.
5 Store the new calibration constants (“Storing the Calibration Constants” on
page 78).
6 Verify the DC Volt age G ain adjustments using the verif ication
procedures beginning on page 66.
Always complete tests in the specified order as shown in the appropriate table.
Each range in the gain adjustment procedure takes less than 2 seconds to complete.
