Agilent 5110/5100 ICP-OES Service Manual Agilent Restricted 263
9 iTroubleshoot/Parts Predict
Problem Solving Table
Poor Precision Poor Precision across multiple
wavelengths
Wavelengths off peak Instrument warm up for 4 hours
Poor Precision Poor Precision across multiple
wavelengths
Wavelengths off peak Perform Instrument Calibration
Pre Optics Pre optics Ready LED Red Beam Combiner Fault Replace Beam combiner Opto
sensor
G8010-65208
Pre Optics Pre optics Ready LED Red Beam Combiner Fault Replace Pre Optics Motor
Control PCA
G8010-65206
Pre Optics Pre optics Ready LED Red Radial Scan Fault Replace radial Scan opto sensor G8010-65208
Pre Optics Pre optics Ready LED Red Radial Scan Fault Replace Pre Optics Motor
Control PCA
G8010-65206
Pre Optics Pre optics Ready LED Red Beam Combiner Fault Replace Beam combiner Opto
sensor
G8010-65208
Pre Optics Pre optics Ready LED Red Beam Combiner Fault Replace Pre Optics Motor
Control PCA
G8010-65206
RF Control RF Ready LED Red RF Comms Error Replace SSRF Control PCA G8010-65205
Signal Drift Signal drift - Thermal Stabilizer
issue
Not at 35°C Wait for stabilization
Signal Drift Signal drift - Polychromator
temperature unstable
Poly not at 35°C Wait for stabilization
Signal Drift Signal drift - Thermal Stabilizer
issue
Not driving to 35°C (No current showing in
diagnostics) Replace Thermal
stabilizer
G8010-60605
Signal Drift Signal drift - Thermal Stabilizer
issue
Not driving to 35°C Replace Mains Power Module
(MPM)
G8010-67300
Signal Drift Signal Drift -Exhaust Extraction
inadequate
Exhaust flow too low Check for correct flow using
tissue
Torch Loader Torch Loader Ready LED Red Torch interlock fault Adjust or replace interlock
switch
G8010-60226
Torch Loader Torch Loader Ready LED Red Torch interlock fault Replace Instrument Control PCA G8010-65200
Torch Loader Torch Loader Ready LED Red Torch not loaded correctly Load Torch
Water Cooling Water Cooling Ready LED Red CCD Water Flow out of
Spec
Replace Water Flow Sensor 110796700
Water Cooling Water Cooling Ready LED Red CCD Water Flow out of
Spec
Replace Instrument Control PCA G8010-65200
Water Cooling Water Cooling Ready LED Red Low Flows for CCD and RF Blocked Water Filter - Clean or
replace
G1833-66024
Water Cooling Water Cooling Ready LED Red SSRF Solenoid Failed Replace Solenoid G8400-60342
Water Cooling Water Cooling Ready LED Red SSRF Solenoid Failed Replace Instrument Control PCA G8010-65200
Water Cooling Water Cooling Ready LED Red SSRF Water Flow out of
Spec
Clear restriction
Water Cooling Water Cooling Ready LED Red SSRF Water Flow out of
Spec
Replace SSRF Flow Sensor 110796700
Water Cooling Water Cooling Ready LED Red Water supply Pressure Check and Adjust
Water Cooling Water Cooling Ready LED Red Water Temp out of spec Check Chiller and adjust
Table 1
Symptom Area Problem Problem Description Solution Part Number(s)
