The Column Oven
Making a temperature-programmed run
88
Making a temperature-programmed run
You can program the oven temperature from an initial temperature to a final
temperature using up to six ramps during a run.
A single ramp temperature program raises the initial oven temperature to a
specified final temperature at a specified rate and holds at the final temperature
for a specified period of time.
Figure 17 Single ramp
The multiple-ramp temperature program is similar. You can program the oven
from an initial temperature to a final temperature, but with various rates, times,
and temperatures in between. Multiple ramps can also be programmed for
temperature decreases as well as increases.
Figure 18 Multiple ramp
Temp
(Init temp)
Init time
Rate
Final time
Final temp
Temp
Final temp 2
Final time 2
Rate 2
Final time 1
Final temp 1
Init time
Rate 1
