The Column Oven
Using the oven insert for fast chromatography
94
Using the oven insert for fast chromatography
The 6890 Oven Insert for Fast Chromatography reduces the oven volume so that
the column and sample heat more quickly, yielding faster separation and faster
chromatography. Furthermore, the smaller volume oven cools faster than a full-
sized oven, reducing the overall analytical cycle time.
Figure 19 Oven insert
The oven insert is used with any inlet, column, and detector mounted in the back
position. It is not compatible with any accessory which obstructs access to the
back of the oven or which requires the use of either the front inlet or the front
part of the oven.
To install the oven insert
1. Turn off your GC oven and allow it to cool.
Caution The cutouts in the interior oven walls may have sharp edges that can damage
the oven insert fabric.
Front Back
Carrying strap
Metal surfaces
may become hot
Warning!
To Next Page
